Designed for Patient-Specific Anatomies

The E-xtra Design MultiBranch Stent Graft System is indicated for the endovascular treatment of patients with type I, II, III, IV or V thoracoabdominal aneurysms according to the Crawford classification or supra-, para- or juxtarenal abdominal aortic aneurysms or dissections extending to the thoracoabdominal aorta.

Product Highlights

• Produced in only 18 working days
• Can be built with different features, for example outer branches, inner branches, semi branches, twin branches, and scallops
• Diameters, lengths, widths, and orientations are patient-specific

SCALLOP
Can be positioned proximally or distally L and B: lengths and widths are patient-specific

OUTER BRANCH
Ø 6 mm, L=15 mm
Ø 7 mm, L=16 mm
Ø 8 mm, L=17 mm
Ante- or retrograde

TWIN BRANCH
Diameters, lengths and widths are patient-specific

INNER BRANCH
Ø 6 mm, L=20 mm
Ø 7 mm, L=20.5 mm
Ø 8 mm, L=21 mm
Ante- or retrograde

SEMI BRANCH
Diameters, lengths and widths are patient-specific

INTEGRATED BIFURCATION(If needed)
Bifurcated shape: Ø10 or 13mm

DELIVERY SYSTEM

1. FLEXIBLE CATHETER (GRAFT COVER)
For accurate pushability and precise trackability.

2. RELEASE HANDLE
With a squeeze-to-release mechanism.

3. CONTROL HANDLE with RELEASE BUTTON with RETAINING RING

Art.nr: 1000 (custom made)
